HEAD PULLEY D500mm FW1050mm BW900mm is a premium heavy-duty conveyor head pulley designed for demanding mining and industrial environments. Engineered for reliability and long service life, it features a robust steel drum, precision-machined shaft, and durable diamond-pattern rubber lagging to maximise traction and minimise belt slip.

SPECIFICATIONS
TYPE: HEAD PULLEY
LAGGING TYPE: Diamond Lagging
LAGGING MATERIAL: Rubber SH65
SHAFT MATERIAL: BMS
LOCKING DEVICE: BIKON 1006
DRIVE CONNECTION: Standard Key-way
SHAFT END: Threaded Connection Hole
PULLEY DIAMETER (PD): D500mm
BELT WIDTH: 900mm
FACE WIDTH (FW): 1050mm
WALL THICKNESS (WT): 10mm
LAGGING THICKNESS (LT): 10mm
SHAFT SIZE: 95mm/85mm/75mm
SHAFT DIAMETER (SD-1): 95mm
SHAFT LENGTH (SL-1): 1050mm
SHAFT DIAMETER (SD-2): 85mm
SHAFT LENGTH (SL-2): 300mm
SHAFT DIAMETER (SD-3): 75mm
SHAFT LENGTH (SL-3): 300mm
TOTAL SHAFT LENGTH (TSL): 1950mm

Note: Any dimensional changes can be requested
